Wall-Mounted Dental X-Ray Unit
60/70 kVp · 8 mA · near-2 m articulating arm · zero floor space
A wall-mounted dental X-ray unit that occupies no floor space at all. The hanger support is nearly 2 metres long, so the doctor can position the beam head from any angle around the chair. Exposure parameters are preset for one-touch quick exposure, and it pairs with our digital intraoral sensor for a filmless workflow.
60 / 70 kVp8 mANear-2 m armPreset parameters57 kg packed
Specifications
NKK10B Technical Parameters
| Power supply | AC 220 V ±10% · 50 Hz · 1 kVA |
|---|---|
| Tube voltage | 60 kVp / 70 kVp (new style) |
| Tube current | 8 mA |
| Focus size | 1.5 mm / 0.8 mm (optional) |
| Total filtration | 2.5 mm Al |
| Exposure time | 0.2 – 4 s |
| Leak radiation | Outside one meter ≤ 0.002 mGy/h (national standard: 0.25 mGy/h) |
| Arm length | Hanger support near 2 m |
| Net weight | 27 kg · packed 57 kg |
| Packing size | 980 × 320 × 450 mm |
Specifications from the manufacturer's product datasheet (Shandong Newheek Imaging Equipment Co., Ltd.). Ask us for the CE / FDA documentation package for your market.
Product Advantages
Why the NKK10B
- Wall-mounted installation — does not occupy floor space
- Low radiation: leakage is only about one percent of the national regulations
- Exposure parameter presets — touch-key selection for quick exposure, saving time
- Hanger support near 2 m — radiography from any position around the chair
- Works with water-washed dental film for rapid imaging
- Pairs with a digital intraoral X-ray imaging system to replace film processing
